Cat5e Shielded Plenum Ethernet Cable 1000ft 24AWG Solid Bare Copper 350MHz CMP ETL Listed
SKU:
4017-Big
Regular price
$327.99
Unit price
-
24AWG Solid Bare Copper · 4 Shielded Twisted Pairs
-
FEP Insulation · Flame Retardant PVC Jacket
-
Aluminum Foil Shield · Blocks EMI and Crosstalk
-
CMP/FT6 Rated · C(ETL) Listed · ANSI/TIA-568-C.2
-
350MHz · Gigabit Ethernet · PoE/PoE+ Support
Save More on Bulk Orders
SAVE MORE
on Bulk OrdersThe more you buy, the more you save!
| QTY | Price Per Item | Your Savings |
|---|---|---|
Need a custom quote?
Contact our team for large volume pricing.
Contact Us
Contact our team for large volume pricing.
Price-match guarantee
FREE shipping
Lifetime warranty
Cat5e Shielded Plenum Ethernet Cable 1000ft 24AWG Solid Bare Copper 350MHz CMP ETL Listed
$327.99
SKU:
4017-Big
Regular price
$327.99
Unit price
-
𝐏𝐋𝐄𝐍𝐔𝐌 𝐂𝐄𝐑𝐓𝐈𝐅𝐈𝐄𝐃 𝐂𝐌𝐏/𝐅𝐓𝟔 CMP/FT6-rated jacket is approved for above-ceiling plenum spaces and also covers riser and in-wall runs in offices, schools, and commercial buildings.
-
𝐀𝐋𝐔𝐌𝐈𝐍𝐔𝐌 𝐅𝐎𝐈𝐋 𝐄𝐌𝐈 𝐒𝐇𝐈𝐄𝐋𝐃 Overall F/UTP aluminum foil shield blocks EMI and reduces crosstalk — ideal for cable runs near HVAC, lighting, and power lines.
-
𝐒𝐎𝐋𝐈𝐃 𝐁𝐀𝐑𝐄 𝐂𝐎𝐏𝐏𝐄𝐑 𝟐𝟒𝐀𝐖𝐆 Solid bare copper conductors deliver maximum conductivity and long-term signal reliability across every permanent installation run.
-
𝐅𝐄𝐏 𝐈𝐍𝐒𝐔𝐋𝐀𝐓𝐈𝐎𝐍 𝐅𝐎𝐑 𝐏𝐋𝐄𝐍𝐔𝐌 FEP insulation handles plenum temperatures and produces less toxic smoke in a fire than standard PVC, meeting the stricter CMP flame requirements.
-
𝐄𝐀𝐒𝐘 𝐏𝐔𝐋𝐋 𝐁𝐎𝐗 𝐈𝐍𝐂𝐋𝐔𝐃𝐄𝐃 1000ft reel-in-box includes ripcord and sequential footage markings for faster pulling, clean jacket removal, and accurate cuts on job sites.
Description
Description
This Cat5e CMP-rated shielded plenum ethernet cable is built for air-handling spaces above drop ceilings and below raised floors. CMP/FT6 is the highest indoor fire rating, covering plenum, riser, and in-wall installs with one spec. 24AWG solid bare copper supports Gigabit Ethernet to 328 feet with 350MHz and PoE/PoE+.
The overall F/UTP aluminum-foil shield blocks EMI and reduces crosstalk near HVAC, lighting, and power lines. FEP insulation handles elevated plenum temperatures and produces less toxic smoke than PVC in a fire, meeting the stricter CMP flame requirements. A ripcord and footage markings make pulls fast and accurate.
Standards: C(ETL) Listed FT6 CMP · C(ETL)US Verified ANSI/TIA-568-C.2 · RoHS Compliant
Technical Specifications:
• Conductor: Solid Bare Copper · AWG: 24 · Pairs: 4 F/UTP (Foil Shielded)
• Insulation: FEP · Jacket: FR-PVC CMP/FT6
• Ripcord: Yes · OD: 0.233 in. · Weight: 31 lbs · NVP: 69%
• Performance: 350MHz · Gigabit to 328ft · PoE/PoE+ (IEEE 802.3af/at)
• Packaging: 1000ft RIB · Colors: Blue, White
Typical Applications:
• Above-ceiling plenum runs in offices, schools, and hotels
• Below-raised-floor commercial installations
• Runs near HVAC equipment, lighting, and power lines
• PoE IP cameras and access points in plenum spaces
• Any install requiring the highest fire-safety rating
