Cat5e Shielded Riser Ethernet Cable 1000ft 24AWG Solid Bare Copper 350MHz CMR ETL Listed
-
24AWG Solid Bare Copper · 4 Shielded Twisted Pairs
-
HDPE Insulation · Flame Retardant PVC Jacket
-
Aluminum Foil Shield · Blocks EMI and Crosstalk
-
CMR/FT4 Rated · C(ETL) Listed · ANSI/TIA-568-C.2
-
350MHz · Gigabit Ethernet · PoE/PoE+ Support
SAVE MORE
on Bulk Orders
The more you buy, the more you save!
| QTY | Price Per Item | Your Savings |
|---|---|---|
| 3–9 units | $249.28 / unit | 3% |
| 10–19 units | $244.14 / unit | 5% |
| 20+ units | $239.00 / unit | 7% |
Price-match guarantee
FREE shipping
Lifetime warranty
Cat5e Shielded Riser Ethernet Cable 1000ft 24AWG Solid Bare Copper 350MHz CMR ETL Listed
-
𝐂𝐌𝐑 𝐑𝐈𝐒𝐄𝐑 𝐑𝐀𝐓𝐄𝐃 𝐅𝐓𝟒 CMR/FT4-rated jacket is approved for in-wall and vertical between-floor installations in offices, residential buildings, and commercial spaces.
-
𝐀𝐋𝐔𝐌𝐈𝐍𝐔𝐌 𝐅𝐎𝐈𝐋 𝐄𝐌𝐈 𝐒𝐇𝐈𝐄𝐋𝐃 Overall F/UTP aluminum foil shield blocks EMI and reduces crosstalk — ideal for cable runs near electrical panels, HVAC, and industrial equipment.
-
𝐒𝐎𝐋𝐈𝐃 𝐁𝐀𝐑𝐄 𝐂𝐎𝐏𝐏𝐄𝐑 𝟐𝟒𝐀𝐖𝐆 Solid bare copper conductors deliver maximum conductivity and long-term signal reliability across every permanent riser and in-wall installation.
-
𝐇𝐃𝐏𝐄 𝐈𝐍𝐒𝐔𝐋𝐀𝐓𝐈𝐎𝐍 High-density polyethylene insulation provides corrosion and chemical resistance with solid-core performance over long-distance runs.
-
𝐏𝐑𝐎 𝐈𝐍𝐒𝐓𝐀𝐋𝐋𝐀𝐓𝐈𝐎𝐍 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒 1000ft Reelex II winding with ripcord and sequential footage markings for tangle-free payout, clean jacket removal, and accurate cuts on the job.
Description
Description
This Cat5e CMR-rated shielded riser ethernet cable is built for in-wall and vertical between-floor installations in residential and commercial buildings. CMR/FT4 is approved for riser and in-wall runs, supporting Gigabit Ethernet to 328 feet with 350MHz bandwidth and PoE/PoE+ (IEEE 802.3af/at).
The overall F/UTP aluminum-foil shield blocks EMI and reduces crosstalk on runs near electrical panels, HVAC, and industrial equipment. HDPE insulation adds corrosion and chemical resistance standard PVC doesn't offer. A ripcord and footage markings make jacket removal and pulls fast and accurate.
Standards: C(ETL) Listed FT4 CMR · C(ETL)US Verified ANSI/TIA-568-C.2 · RoHS Compliant
Technical Specifications:
• Conductor: Solid Bare Copper · AWG: 24 · Pairs: 4 F/UTP (Foil Shielded)
• Insulation: HDPE · Jacket: FR-PVC CMR/FT4
• Ripcord: Yes · OD: 0.242 in. · Weight: 30 lbs · NVP: 69%
• Performance: 350MHz · Gigabit to 328ft · PoE/PoE+ (IEEE 802.3af/at)
• Packaging: 1000ft Reelex II · Colors: Black, Blue, Gray, White, Yellow, Green
Typical Applications:
• In-wall and vertical riser runs between floors
• Structured cabling for offices and commercial buildings
• Runs near electrical panels, HVAC, and industrial equipment
• PoE IP cameras and wireless access points
• Color-coded cable management across multi-drop installs
