Shielded Fire Alarm Cable 14AWG 2 Solid Conductors Bare Copper FPLR Riser 1000ft Red
-
14AWG Solid Bare Copper · 2 Conductors Black/Red
-
AL-Foil Shield + Drain Wire · PVC Insulation
-
C(UL) Listed FPLR · UL 1424 · UL 1666
-
OD 0.220 in. · 43 lbs/1000ft · Temp 75°C
-
FR-PVC Jacket · Rip Cord · NEC Article 760
SAVE MORE
on Bulk Orders
The more you buy, the more you save!
| QTY | Price Per Item | Your Savings |
|---|---|---|
| 3–9 units | $422.91 / unit | 3% |
| 10–19 units | $414.19 / unit | 5% |
| 20+ units | $405.47 / unit | 7% |
Price-match guarantee
FREE shipping
Lifetime warranty
Shielded Fire Alarm Cable 14AWG 2 Solid Conductors Bare Copper FPLR Riser 1000ft Red
-
𝐅𝐏𝐋𝐑 𝐑𝐀𝐓𝐄𝐃 𝐅𝐎𝐑 𝐑𝐈𝐒𝐄𝐑 𝐑𝐔𝐍𝐒 FPLR rating meets NEC Article 760 for vertical riser shafts between floors — and also substitutes for FPL in any non-plenum location in the building.
-
𝟏𝟒𝐀𝐖𝐆 𝐅𝐎𝐑 𝐌𝐀𝐗 𝐍𝐀𝐂 𝐃𝐈𝐒𝐓𝐀𝐍𝐂𝐄 14AWG has the lowest resistance in the fire alarm range — for the longest NAC runs and highest device counts where 16AWG or 18AWG cause voltage drop.
-
𝐀𝐋-𝐅𝐎𝐈𝐋 𝐁𝐋𝐎𝐂𝐊𝐒 𝐄𝐌𝐈 𝐀𝐍𝐃 𝐑𝐅𝐈 AL-foil shield and drain wire block EMI from motors, HVAC, and electrical panels — keeping alarm signals clean in large commercial buildings.
-
𝐒𝐎𝐋𝐈𝐃 𝐁𝐀𝐑𝐄 𝐂𝐎𝐏𝐏𝐄𝐑 𝟏𝟒𝐀𝐖𝐆 Solid bare copper delivers maximum conductivity and long-term electrical performance for demanding notification circuits across the full 1000ft reel.
-
𝐈𝐍𝐒𝐓𝐀𝐋𝐋𝐄𝐑-𝐑𝐄𝐀𝐃𝐘 𝐑𝐄𝐄𝐋 Red jacket for instant fire alarm identification. Rip cord for fast jacket removal. Sequential footage markings. 1000ft reel for large installations.
Description
Description
FPLR-rated 14AWG shielded fire alarm cable for vertical riser runs in shafts and between floors. FPLR is the riser rating under NEC Article 760 — required wherever fire alarm circuits run vertically through more than one floor. FPLR substitutes for FPL; FPLP substitutes for FPLR.
14AWG is the heaviest gauge in the standard fire alarm range — lowest resistance, highest current, and longest notification appliance circuit (NAC) reach before voltage drop becomes a problem. The aluminum foil shield with drain wire blocks EMI from motors, HVAC, and electrical panels. Also commonly used for security and burglar alarm wiring on the same job.
Standards: C(UL) Listed FPLR · UL 1424 · UL 1666 · RoHS Compliant
Technical Specifications:
• Conductor: Solid Bare Copper · AWG: 14 · Conductors: 2 (Black/Red)
• Shield: AL-Foil + Drain Wire (Stranded TC) · Insulation: PVC
• Jacket: FR-PVC FPLR · Rip Cord: Yes · Color: Red
• OD: 0.220 in. · Weight: 43 lbs · Rated Temp: 75°C
• Packaging: 1000ft Reel
Typical Applications:
• Vertical riser runs in shafts and stairwells between floors
• Notification appliance circuits (NAC) — horns, strobes, sirens
• Addressable fire alarm and detection systems
• Runs near motors, HVAC, and electrical panels requiring EMI shielding
• Combined fire alarm and security/burglar alarm wiring
