8U Wall Mount Server Rack Open Frame 18in Deep for 19in IT Network Equipment Steel Black
-
8U · 18in Deep · 19in EIA Compliant
-
Heavy-Duty Steel · Black Textured Powder Coat
-
150 lb Weight Capacity
-
#12-24 Tapped Rails · Numbered Markings
-
19.6” W x 17.8” H x 18.0” D · Unassembled
SAVE MORE
on Bulk Orders
The more you buy, the more you save!
| QTY | Price Per Item | Your Savings |
|---|---|---|
| 3–9 units | $139.67 / unit | 3% |
| 10–19 units | $136.79 / unit | 5% |
| 20+ units | $133.91 / unit | 7% |
Price-match guarantee
FREE shipping
Lifetime warranty
-
𝐒𝐀𝐕𝐄𝐒 𝐀 𝐃𝐄𝐃𝐈𝐂𝐀𝐓𝐄𝐃 𝐒𝐄𝐑𝐕𝐄𝐑 𝐑𝐎𝐎𝐌 Mount 8U of switches and patch panels on any wall — no floor space, no server room, no extra construction cost.
-
𝐅𝐈𝐓𝐒 𝐖𝐇𝐄𝐑𝐄 𝐅𝐋𝐎𝐎𝐑 𝐑𝐀𝐂𝐊𝐒 𝐂𝐀𝐍'𝐓 18in usable depth in IDF closets, utility rooms, and tight spaces — same equipment capacity, zero floor footprint.
-
𝐎𝐏𝐄𝐍 𝐅𝐑𝐀𝐌𝐄 𝟏𝟓𝟎 𝐋𝐁 𝐂𝐀𝐏𝐀𝐂𝐈𝐓𝐘 No side panels to block airflow or slow you down — full front/rear access, rated to hold 150 lbs of gear.
-
𝐅𝐋𝐀𝐓-𝐏𝐀𝐂𝐊 𝟐-𝐏𝐈𝐄𝐂𝐄 𝐀𝐒𝐒𝐄𝐌𝐁𝐋𝐘 Ships unassembled with hardware and instructions — no bulky pre-built frame to carry up a ladder or through a door.
-
𝐂𝐀𝐁𝐋𝐄 𝐓𝐈𝐄 𝐏𝐎𝐈𝐍𝐓𝐒 𝐁𝐔𝐈𝐋𝐓 𝐈𝐍 Lacing slots on both panels mean zero-cost cable management from install day — no separate kit to buy.
Description
Description
Mount up to 8U of 19-inch network and server equipment without floor space with this open frame wall rack, built for intermediate distribution frame (IDF) areas — a cost-effective alternative to bulky 2-post or 4-post floor racks.
Heavy-duty steel construction with a black textured powder coat finish supports up to 150 lbs of equipment. The two-piece design — top panel, bottom panel, and two vertical rails — features #12-24 tapped, EIA-compliant rack rails with number markings for fast equipment placement, plus built-in cable tie point slots for clean routing. Open frame construction maximizes airflow and gives instant front and rear access to mounted equipment.
Standards: EIA/ECA-310-E Compliant · RoHS
Technical Specifications:
• Rack Size: 8U · Depth: 18 in. · Width: 19.6 in. (19in EIA)
• Height: 17.8 in. · Weight Capacity: 150 lbs
• Material: Heavy-Duty Steel · Finish: Black Textured Powder Coat
• Rails: #12-24 Tapped, EIA Compliant, Numbered
• Package: Top Panel, Bottom Panel, 2 Vertical Rails, Hardware, Instructions — Unassembled
Typical Applications:
• Intermediate distribution frame (IDF) network closets
• Wall-mounted switch, patch panel, and patch cable staging
• Floor-restricted server and network rooms
• Alternative to floor-standing 2-post/4-post racks
• Small office and branch network installations
